Bohemia, New York (July 2013) Data Device Corporation (DDC) introduces the PCIe-Express AceXtreme® component. The BU-67302B0C0L-202 provides dual MIL-STD-1553 transceivers, protocol, and 64K x 36 of internal memory within a single BGA device with a PCI-Express host interface. It is ideal for industrial temperature range applications (-40°C to +85°C) where PCB space is at a premium, due to its compact size of just 15 mm x 20 mm, and its low power dissipation.

The device provides a dual redundant MIL-STD-1553 channel with very low power, less than 1.1W power dissipation @ 50% duty cycle. It includes an IEEE 1149.1 compliant JTAG test interface to support boundary scan testing of circuit assemblies, a digital IRIG-B input, and 8 digital discrete I/O lines.

Benefits include:

• Ultra Small Size and Efficiency Saves Space and Power
• Replaces 2 Transceivers, MIL-STD-1553 Protocol Core, and Memory
• Single Package with PCIe Board Design
• RT Validated to Simplify SAE-AS4112 Qualification
• RoHS Version Available

“The PCI-Express AceXtreme® saves board space and power, while simplifying MIL-STD-1553 board design and layout by utilizing a commonly available, high performance, serial back end interface to the host processor”, stated Sean Sleicher, DDC’s Data Bus Marketing Manager.
