Miniature Low-Profile Power Inductor MIL-PRF-27

Version:

BPI-00051, BPI-00052, BPI-00053, BPI-00054, BPI-00101, BPI-00102, BPI-00103, BPI-00104, BPI-00251, BPI-00252, BPI-00253, BPI-00254, BPI-00501, BPI-00502, BPI-00503, BPI-00504, BPI-00751, BPI-00752, BPI-00753, BPI-00754, BPI-01001, BPI-01002, BPI-01003, BPI-01004, BPI-02001, BPI-02002, BPI-02003, BPI-02004, BPI-03001, BPI-03002, BPI-03003, BPI-03004, BPI-05001, BPI-05002, BPI-05003, BPI-05004, BPI-07501, BPI-07502, BPI-07503, BPI-07504, BPI-10001, BPI-10002, BPI-10003, BPI-10004, BPI-15002, BPI-15003, BPI-15004, BPI-20002, BPI-20003, BPI-20004

Base Part #:

BPI Series

Package:

N/A

Lead Free Code:

A

Status:

Standard

Quantity:

Add to Quote Tech Support

Beta's BPI series inductors provide high power and high performance in a miniature sized package, designed to meet the SWaP requirements of today's military and industrial applications.

Drop-in Pin for Pin Replacement for Pico Electronics:

40000 series
41000 series
42000 series
43000 series

All Inductors have Split Windings
Miniature package requires less board space
Low Profile
Surface Mount
- Tape and Reel Available
-55°C to +130°C Operating Temperature Range
Built and Tested to MIL-PRF-27 Grade 5 Class S
Available RoHS Compliant
Precision Formed Leads

Datasheet

BPI Series Datasheet

Rev: A ( Pages, 250 KB)

Product Catalog

DDC Product Catalog

Rev: 8 (84 Pages, 33.60 MB)
